9m Locking Pneumatic Telescopic Mast 30kg Payload 2.2m closed height
Item#: NR-2.2-9.0-30L-6S-51-140
1> Extended height: 9m
2> Retradted height: 2.2m
3> Vertical Payload: 30kg (0.15MPa/22 PSI working air pressure)
4> Number of sections: 6 sections
5> Section dia. : 51mm~140mm
6> Materials: aluminum alloy 6063T5
7> Mast weight 55kg approx.
8> Installation: vertical and upward
9> Default accessories: top flange, bottom flange, air hose pipe, air control manual, guying ropes/wires mounting plate and eyebolts
10> Chargeable accesssories: side mounting bracket NR-S140, ground mounting tripod NR-TRIPOD140, guide rope kits (2 layers, 4 ropes each layer, 9m mounting radius), electric air compressor DC12V, DC24V, AC220V or compact electric control box with remote controller
Leading time: 20 days
Guarantee: one year
The latest information has been updated on 20250111
Information is subject to change without notice
9m Locking Pneumatic Telescopic Mast 30kg Payload 2.2m closed height
Item#: NR-2.2-9.0-30L-6S-51-140
1> Extended height: 9m
2> Retradted height: 2.2m
3> Vertical Payload: 30kg (0.15MPa/22 PSI working air pressure)
4> Number of sections: 6 sections
5> Section dia. : 51mm~140mm
6> Materials: aluminum alloy 6063T5
7> Mast weight 55kg approx.
8> Installation: vertical and upward
9> Default accessories: top flange, bottom flange, air hose pipe, air control manual, guying ropes/wires mounting plate and eyebolts
10> Chargeable accesssories: side mounting bracket NR-S140, ground mounting tripod NR-TRIPOD140, guide rope kits (2 layers, 4 ropes each layer, 9m mounting radius), electric air compressor DC12V, DC24V, AC220V or compact electric control box with remote controller
Leading time: 20 days
Guarantee: one year
The latest information has been updated on 20250111
Information is subject to change without notice
| 9m Lockable Pneumatic Telescopic Mast-30kg Payload | ||||||
| NR-2.2-9.0-30L-6S-51-140 | ||||||
 | ||||||
| Extended Height | : | 9 | m | 29.52 | ft | |
| Retracted Height | : | 2.2 | m | 7.2 | ft | |
| Vertical Payload | : | 30 | kg | 66 | lb | |
| Working air pressure | : | 0.15 | Mpa | 22 | PSI | |
| Collar Type | : | Locking (Automatic Extension, Manual Retraction) | ||||
| Inside Electric Wires | : | |||||
| Number of sections | : | 6 | ||||
| Top section diameter | : | 51 | mm | 2.0 | in | |
| Basement section diameter | : | 140 | mm | 5.5 | in | |
| Mast Weight | : | 55 | kg | 121 | lb | |
| Working temperature | : | -25~65 Celsius Degree | ||||
| Materials | : | Aluminum alloy 6063T5 | ||||
| Default accessories | : | top flange | ||||
| bottom flange | ||||||
| air hose pipe | ||||||
| air control manual | ||||||
| guying ropes/wires mounting plate and eyebolts | ||||||
| Optional Accessories | : | Electric air compressor | DC12V, DC24V, AC220V/50hz | |||
| Guying Rope Kits | 2x4 (2 layers, 4 ropes each layer, 4 mounting spikes, mounting radius 9m) | |||||
| Side Mounting Bracket | Aluminum alloy 6061 Materials | |||||
| Ground mounting Tripod | Stainless Materials | |||||
| Rotation Basement | Manual Rotation | |||||
| Remote control kit | 12VDC | |||||
| the latest data has been updated on 20250111 | ||||||
