9m Locking Pneumatic Telescopic Mast 50kg Payload 2.2m closed height
Item#: NR-2.2-9-50L-6S-66-160
1> Extended Height: 9m
2> Closed Height: 2.2m
3> Vertical Payloads: 50kg payloads@0.15Mpa/22PSI
4> Type: Lockable (automatic elevation/retraction by manual)
5> Number of sections: 6 sections
6> Section dia.: 66mm~160mm
7> Installation: vertical and upward
8> Materials: aluminum alloy 6063T5
9> Mast weight：70kg approx.
10> Default Accessories： 1x top flange, 1x bottom flange, 1x air hose pipe, 1x safety pressure relief valve, guying ropes/wires mounting plate and eyebolts, air control valve
11> Working temperature: -25~65 Celsius Degrees
Optional Accessories:
Eelectric compressor DC12V, DC24V, AC220V or electric control box (Wireless remote control)
ground mounting tripod bracket/quadpod bracket
2x4 guying ropes kits for 120km/h wind speed
vehicle side mounting brackets
Leading time: 20 days
Guarantee: one year
The latest information has been updated on 20250111
Information is subject to change without notice
9m Locking Pneumatic Telescopic Mast 50kg Payload 2.2m closed height
Item#: NR-2.2-9-50L-6S-66-160
1> Extended Height: 9m
2> Closed Height: 2.2m
3> Vertical Payloads: 50kg payloads@0.15Mpa/22PSI
4> Type: Lockable (automatic elevation/retraction by manual)
5> Number of sections: 6 sections
6> Section dia.: 66mm~160mm
7> Installation: vertical and upward
8> Materials: aluminum alloy 6063T5
9> Mast weight：70kg approx.
10> Default Accessories： 1x top flange, 1x bottom flange, 1x air hose pipe, 1x safety pressure relief valve, guying ropes/wires mounting plate and eyebolts, air control valve
11> Working temperature: -25~65 Celsius Degrees
Optional Accessories:
Eelectric compressor DC12V, DC24V, AC220V or electric control box (Wireless remote control)
ground mounting tripod bracket/quadpod bracket
2x4 guying ropes kits for 120km/h wind speed
vehicle side mounting brackets
Leading time: 20 days
Guarantee: one year
The latest information has been updated on 20250329
Information is subject to change without notice
| 9m Lockable Pneumatic Telescopic Mast-50kg Payload | ||||||
| NR-2.2-9-50L-6S-66-160 | ||||||
 | ||||||
| Extended Height | : | 9 | m | 29.52 | ft | |
| Retracted Height | : | 2.2 | m | 7.2 | ft | |
| Vertical Payload | : | 50 | kg | 110 | lb | |
| Working air pressure | : | 0.15 | Mpa | 22 | PSI | |
| Collar Type | : | Locking (Automatic Elevation, Manual Retraction) | ||||
| Inside Electric Wires | : | |||||
| Number of sections | : | 6 | ||||
| Top section diameter | : | 66 | mm | 2.6 | in | |
| Basement section diameter | : | 160 | mm | 6.3 | in | |
| Mast Weight | : | 70 | kg | 154 | lb | |
| Working temperature | : | -25~65 Celsius Degree | ||||
| Materials | : | Aluminum alloy 6063T5 | ||||
| Default accessories | : | top flange | ||||
| bottom flange | ||||||
| air hose pipe | ||||||
| air control manual valve | ||||||
| guying ropes/wires mounting plate and eyebolts | ||||||
| Optional Accessories | : | Electric air compressor | DC12V, DC24V, AC220V/50hz | |||
| Guying Rope Kits | 2x4 (2 layers, 4 ropes each layer, 4 mounting spikes, mounting radius 9m) | |||||
| Side Mounting Bracket | Aluminum alloy 6061 Materials | |||||
| Ground mounting Tripod/Quadpod | 40kg approx. | |||||
| Rotation Basement | Manual Rotation | |||||
| Remote control kit | 12VDC | |||||
| data update on 20250111 | ||||||
