12m Locking Mast 50kg Payload NR-2.7-12-50L-7S-66-180
❤ Add to collection

12m Locking Mast 50kg Payload NR-2.7-12-50L-7S-66-180

12m Locking Pneumatic Telescopic Mast 50kg payloads-2.7m closed height
Item #: NR-2.7-12-50L-7S-66-180
1> Extended Height: 12m
2> Closed Height: 2.7m
3> Vertical Payloads: 50kg payloads @ 0.2Mpa/29 PSI
4> Type: Lockable mast (automatic extension/ retraction by manual operating)
5> Number of sections: 7 sections
6> Section diameter: 66mm~180mm
7> Materials: Aluminum alloy 6063T5 material, hard anodization finish
8> Mast weight: 100 kg
9> Working air pressure: 0.2Mpa/29PSI as recommend
10> Working temperature: -25°C~55°C
11> Default accessories: 1x top flange, 1x bottom flange, 1x air hose pipe, 1x air control manual, 1x retraction tool, guy ropes mounting plate and eyebolts.

Optional and Charging accessories:
Ground mounting tripod/quadpod (stainless materials), Guying rope kits (2 layers, 8 ropes/wires, 4 mounting spikes, mounting radius 12m), Side mounting bracket (aluminum alloy materials), Electric air compressor (DC12V, DC24V, AC220V/50hz), Remote control kit

Guarantee: two years
Leading time: 30 days
the latest data was updated on 20260306
