15m Locking Mast-350kg Payload-3.3m Retract NR-3.3-15-350L-160-316
❤ Add to collection

15m Locking Mast-350kg Payload-3.3m Retract NR-3.3-15-350L-160-316

15m Locking Pneumatic Telescopic Mast-350kg Payload
Item #: NR-3.3-15-350L-160-316
1> Extended Height: 15m
2> Retracted Height: 3.3m
3> Vertical Payloads: 350kg @ 0.25Mpa/36PSI
4> Collar: Lockable (automatic extension, manual operating retraction, suitable for long time deployment weekly, monthly or yearly)
5> Number of sections: 7 pcs
6> Sections diameter range: 160mm~316mm
7> Materials: Aluminum alloy 6063T5
8> Mast weight: 353kg approx.
9> Default accessories: top flange, bottom flange, air hose pipe, air control manual, manual operation tool

10> Charging accessories: electric air compressor 3000W, AC220V/50hz, ground mounting quadpod bracket, guide rope kits, side mounting bracket (steel materials, 30kg approx.), remote control kit

Guarantee: two years
leading time: 40 days
the latest data updated on 2026.02.08

U.S.＄0.00
0.00
U.S.＄0.00
U.S.＄0.00
Weight：0.000KG
Quantity：
(Inventory: 0)
Buy now
Add to cart
Products Description

15m Locking Pneumatic Telescopic Mast-350kg Payload
Item #: NR-3.3-15-350L-160-316
1> Extended Height: 15m
2> Retracted Height: 3.3m
3> Vertical Payloads: 350kg @ 0.25Mpa/36PSI
4> Collar: Lockable (automatic extension, manual operating retraction, suitable for long time deployment weekly, monthly or yearly)
5> Number of sections: 7 pcs
6> Sections diameter range: 160mm~316mm
7> Materials: Aluminum alloy 6063T5
8> Mast weight: 353kg approx.
9> Default accessories: top flange, bottom flange, air hose pipe, air control manual, manual operation tool

10> Charging accessories: electric air compressor 3000W, AC220V/50hz, ground mounting quadpod bracket, guide rope kits, side mounting bracket (steel materials, 30kg approx.), remote control kit

Guarantee: two years
leading time: 40 days
the latest data updated on 2026.02.08

15m Locking Pneumatic Telescopic Mast-350kg Payload
Item #: NR-3.3-15-350L-160-316
1> Extended Height: 15m
2> Retracted Height: 3.3m
3> Vertical Payloads: 350kg @ 0.25Mpa/36PSI
4> Collar: Lockable (automatic extension, manual operating retraction, suitable for long time deployment weekly, monthly or yearly)
5> Number of sections: 7 pcs
6> Sections diameter range: 160mm~316mm
7> Materials: Aluminum alloy 6063T5
8> Mast weight: 353kg approx.
9> Default accessories: top flange, bottom flange, air hose pipe, air control manual, manual operation tool

10> Charging accessories: electric air compressor 3000W, AC220V/50hz, ground mounting quadpod bracket, guide rope kits, side mounting bracket (steel materials, 30kg approx.), remote control kit

Guarantee: two years
leading time: 40 days
the latest data updated on 2026.02.08


15m Lockable Pneumatic Telescopic Mast-350kg Payload
NR-3.3-15-350L-7S-160-316
Extended Height:15m49.2ft
Retracted Height:3.3m10.8 ft
Vertical Payload:350kg770lb
Working air pressure:0.25Mpa37 PSI
Collar Type:Locking (Automatic Extension, Manual Retraction)
Inside Electric Wires:



Number of sections:7



Top section diameter:160mm6.3 in
Basement section diameter:316mm12.4 in
Mast Weight:353kg776.6lb
Working temperature:-25~65 Celsius Degree
Materials:Aluminum alloy 6063T5
Default accessories:top flange
bottom flange
air hose pipe
air control manual
Retraction operation tool
Optional Accessories:Electric air compressorAC220V/50hz, 3000W
Guy Rope Kits3x4 (3 layers, 4 ropes each layer, 4 mounting stakes, mounting radius 15m)
Side Mounting BracketSteel Materials, 30kg approx.
Ground mounting QuadpodStainless Material
Rotation Basement
Remote control kit AC220V/50Hz
data update on 20260208
